UZ1084L33TQ2T 可调电压5V稳压器

  • 低压差电压
  • 负载调整率:0.05% 典型值
  • 快速瞬态响应
  • 片上热限制


电压 Voltage 3.3V
家庭电压范围 Family Voltage Range 1.5 to 5
电源电压(最大) Supply Voltage (maximum) 15V
输出电流 Output Current 5,000mA
压降电压 Drop-out Voltage 1.5V
参考电压容差 Voltage Reference Tolerance 1.6%
纹波抑制比 Ripple Rejection Ratio
输出可调 Output Adjustable Yes
噪声旁路终端 Noise Bypass Terminal No
输出噪声电压 Output Noise Voltage
静态电流 Quiescent Current 13 mA
输出电容 Output Capacitor 22μ


UZ1084L 是一款具有 5A 输出电流能力的低压差三端稳压器。



The UZ1084L is a low dropout three-terminal regulator with 5A output current capability.

It has been optimized for low voltage applications where transient response and minimum input voltage are critical.

On-chip thermal limiting provides protection against any combination of overload and ambient temperature that would create excessive junction temperatures.
