NJM2164M 四路JFET输入运算放大器

  • J-FET 输入


电路数 Number of Circuits 4
电源电压(最低) Supply Voltage (minimum) ±2V
电源电压(最大) Supply Voltage (maximum) ±18V
输入失调电压 Input Offset Voltage 15mV
输入失调电流 Input Offset Current 1nA
输入偏置电流 Input Bias Current 0.002nA
电源电流 Supply Current 0.6mA
增益带宽积 Gain Bandwidth product
压摆率 Slew Rate 10V/μs
噪音 Noise 45nV/√Hz(en)


NJM2164M 是一款四通道、表面贴装、J-FET 输入运算放大器,是流行的 NJM064M 运算放大器的改进版本。



The NJM2164M is a quad,surface mount,J-FET input operational amplifier and represents an improved version of the popular NJM064M op-amp.

It features wider bandwidth, higher slew rate and a wide supply voltage range.

It is suitable for use in many applications including active filters and telecommunications.
